Hirschmann BRS50-00242Q2Q-ETDZ99HHSEAXX.X.XX 942170999 BRS50
Hirschmann BRS50-00242Q2Q-ETDZ99HHSEAXX.X.XX 942170999 BRS50 24-Port BOBCAT Switch
Request a quote for Hirschmann BRS50-00242Q2Q-ETDZ BOBCAT switch with 20 Gigabit RJ45 ports and four 2.5G SFP uplinks.
Hirschmann BRS50 24-port BOBCAT industrial switch
Hirschmann BRS50 24-port BOBCAT industrial switch
Hirschmann BRS50 24-Port BOBCAT Managed Switch Available
HKXY is accepting quotation requests for the Hirschmann BRS50-00242Q2Q-ETDZ99HHSEAXX.X.XX BOBCAT managed industrial Ethernet switch.
Designed for high-density industrial networks, this BRS50 configuration combines 20 Gigabit RJ45 ports with four multi-speed SFP uplink slots. It provides a total of 24 network ports in a compact, fanless DIN-rail platform.
Customers can contact HKXY for current availability, price, estimated lead time and international shipping options.
Product Identification
• Brand: Hirschmann
• Manufacturer group: Belden
• Product family: BOBCAT BRS50
• Complete configuration: BRS50-00242Q2Q-ETDZ99HHSEAXX.X.XX
• Configurator part number: 942170999
• Product type: Managed industrial Ethernet switch
• Installation: DIN rail
• Total network ports: 24
• Copper ports: 20 × 10/100/1000BASE-T RJ45
• Fiber uplinks: 4 × SFP slots
• SFP data rates: 100/1000/2500 Mbit/s
• Local management interface: USB-C
• Design: Fanless
The complete configuration code must be supplied when requesting a quotation. The number 942170999 identifies the BOBCAT configurable-product platform and may be associated with multiple BRS variants.
High-Density Gigabit Connectivity
The BRS50-00242Q2Q configuration provides 20 Gigabit copper access ports for connecting industrial devices such as:
• Programmable logic controllers
• Human-machine interfaces
• Industrial computers
• Remote I/O systems
• Machine controllers
• IP cameras
• Engineering workstations
• Other Ethernet-enabled field equipment
Four SFP slots provide flexible fiber uplink options. Depending on the selected compatible transceiver, the slots can support 100 Mbit/s, 1 Gbit/s or 2.5 Gbit/s connections.
This allows network designers to increase uplink bandwidth without replacing the complete switch.
SFP transceivers are normally selected separately according to the required fiber type, transmission distance, connector and environmental rating.
Designed for Demanding Industrial Environments
The ETD hardware section identifies a configuration intended for demanding operating environments.
According to the BRS product-code structure, this configuration includes:
• Extended operating-temperature design
• Conformal coating
• Redundant DC power-input capability
• IP30 metal housing
• Fanless operation
• DIN-rail installation
The extended-temperature construction and conformal coating make this version particularly relevant for industrial control cabinets exposed to wider temperature changes or environmental contaminants.
Final temperature limits, approvals and environmental specifications should be confirmed using the technical data sheet generated for the complete configuration.
Redundant Power Inputs
The switch platform supports two DC power inputs, helping network designers create a more resilient power arrangement.
If one connected power source fails, the second correctly configured source can help maintain switch operation. Actual redundancy depends on the complete system design, wiring and power-supply arrangement.
A plug-in terminal block is used for power and signaling connections. Installation must be completed by qualified personnel following current Hirschmann instructions.
USB-C Management Interface
The local USB-C interface supports approved local management and device-replacement workflows.
It should not be confused with a standard Ethernet data port. Customers should refer to the relevant Hirschmann documentation for supported configuration and replacement procedures.
Managed Network Functions
Depending on the supplied HiOS software configuration and version, the BOBCAT platform supports managed-network functions used in industrial automation, including:
• VLAN segmentation
• Quality of Service
• Port configuration
• Network diagnostics
• Multicast management
• Link monitoring
• Industrial redundancy
• Access-control and security functions
• Traffic prioritization
• Time-sensitive networking capabilities
Available features can depend on the exact software level and firmware version. Confirm required protocols and licenses before ordering.
Typical Applications
The 24-port BRS50 configuration is suitable for applications requiring many local copper connections and high-speed fiber uplinks, including:
• Factory automation networks
• Production-line control systems
• Automotive manufacturing
• Power and utility installations
• Water and wastewater facilities
• Transportation infrastructure
• Oil and gas facilities
• Process automation
• Machine-building projects
• Industrial surveillance networks
• Control-room connectivity
• Network modernization projects
Why Choose the 24-Port Version?
This model may be suitable when:
• More than eight local Gigabit copper ports are required
• A control cabinet contains many Ethernet devices
• Four fiber uplinks are needed
• 2.5 Gigabit uplink capability is preferred
• A metal IP30 enclosure is specified
• Extended temperature and conformal coating are required
• Fanless DIN-rail installation is preferred
The 24-port version can reduce the number of separate access switches required in a high-density cabinet.
Information Required for a Quote
For an accurate quotation, please provide:
• Complete configuration:
BRS50-00242Q2Q-ETDZ99HHSEAXX.X.XX
• Configurator number: 942170999
• Required quantity
• Delivery country and postal code
• Requested delivery date
• Required approvals
• Required software or firmware level
• Required SFP transceivers
• Existing product-label photo, if replacing a switch
Request a Quote from HKXY
Contact HKXY for Hirschmann BRS50-00242Q2Q-ETDZ99HHSEAXX.X.XX pricing, availability and delivery information.
Email: becky@hkxytech.com
Mobile / WhatsApp / WeChat: +86 15972186287
[GET BRS50 24-PORT PRICE]
HKXY can assist with configuration verification, commercial quotation, available technical documents, lead-time confirmation and worldwide shipping options.
Important Ordering Notice
Do not order this product using only 942170999. This number is used as a BOBCAT configurator part number and does not uniquely identify every hardware, approval and software option.
Always include the complete string:
BRS50-00242Q2Q-ETDZ99HHSEAXX.X.XX
